Honda Hedge Trimmer Hhh25d Workshop Manual Online
| # | Part | Price |
|---|---|---|
| 1 | 16010-ZM3-004 - Honda Gasket, Metering Diaphrag | £3.10 |
| 2 | 16011-Z0H-013 - Honda Gasket, Pump | £3.59 |
| 3 | 16013-Z0H-003 - Honda Diaphragm Assy., Metering | £23.27 |
| 4 | 16014-ZM3-004 - Honda Diaphragm, Pump | £4.31 |
| 5 | 16015-Z0H-013 - Honda Body Assy., Pump | £30.12 |
| 6 | 16017-ZM3-004 - Honda Body Assy., Air Purge | £11.08 |
| 7 | 16018-ZM3-802 - Honda Screen, Inlet | £2.75 |
| 8 | 16019-ZM3-004 - Honda Valve, Inlet Needle | £3.80 |
| 9 | 16020-ZM3-004 - Honda Spring, Metering Lever | £1.91 |
| 10 | 16021-ZM3-004 - Honda Screw, Metering Lever Pin | £1.93 |
| 11 | 16022-ZM3-014 - Honda Pin, Metering Lever | £1.96 |
| 12 | 16023-ZM3-004 - Honda Lever, Metering | £2.47 |
| 13 | 16024-Z0H-003 - Honda Ring, Retaining | £1.97 |
| 14 | 16025-ZM3-004 - Honda O-Ring | £2.29 |
| 15 | 16026-ZM3-004 - Honda Cover, Primer Pump | £3.77 |
| 16 | 16027-ZM3-004 - Honda Swivel | £4.14 |
| 17 | 16028-ZM3-004 - Honda Screw, Throttle Collar | £1.49 |
| 18 | 16029-ZM3-004 - Honda Screw, Pump Cover | £1.49 |
| 19 | 16030-ZM3-004 - Honda Spring, Pump | £1.42 |
| 20 | 16031-ZM3-004 - Honda Washer | £1.49 |
| 21 | 16032-ZM3-004 - Honda Pump, Primer | £4.18 |
| 22 | 16035-ZM3-802 - Honda Filter, Fuel Inlet | £13.63 |
| 23 | 16100-Z0H-053 - Honda Carburetor Assy. (Wyb 6F/ | £77.21 |
| 24 | 16221-ZM3-000 - Honda Packing, Carburetor | £1.91 |
| 25 | 16222-Z0H-800 - Honda Packing, Shroud | £8.71 |
| 27 | 19631-Z0H-000 - Honda Shroud | £11.59 |
| 28 | 19632-Z0H-800 - Honda Spacer, Shroud | £10.39 |
| 29 | 90011-Z0H-801 - Honda Bolt, Socket, 5X10 | £0.82 |
| 30 | 90014-Z0H-801 - Honda Bolt, 5X59 | £2.83 |
| 31 | 90018-Z0H-003 - Honda Bolt, Socket, 5X16 | £0.83 |
| 32 | 90401-Z0H-000 - Honda Washer | £4.42 |
| 33 | 91301-ZM3-000 - Honda O-Ring, 14.8X2.4 | £1.19 |
| 34 | 91308-Z0H-003 - Honda O-Ring, 12.3X2.4 | £1.19 |
| 35 | 99101-Z0H0320 - Honda Jet (#32) | £7.72 |
Honda Hedge Trimmer Hhh25d Workshop Manual Download
Refer to the Honda shop manual for tube replacement instructions, or APPLICATIONS take the trimmer to an authorized Honda servicing dealer. Page 20 A dull blade can be sharpened, but a blade that is worn out, bent, cracked, chipped, or otherwise damaged must be replaced. The hedge trimmer attachment is part of Honda's exclusive VersAttach System. It is interchangeable with any of 5 other options: trimmer, edger, pruner, cultivator, and blower. Pairs with both the UMC425 and UMC435 Powerheads.
